Single Pump Cementing Skid
Single Pump Cementing Skid
The PCS-611A Automatic Density Control single pump cementing skid is a new generation of cementing equipment utilizing the TPC600 piston pump and the ACM automatic mixing system. The extended length TPC600 piston pump is characterized by the advantages of the TPB piston pump, which makes packing replacement and maintenance easier, making it an ideal pump for single-pump cementing units.
Product Specification
|
Max. working Pressure |
44MPa(w/ 4 1/2" fluid end) |
|
Max. Flow |
2.1m3/min (w/ 4 1/2" fluid end) |
|
Density range |
1.3-2.5g/cm3 |
|
Auto control precision |
±0.02 g/cm3 |
|
Mixing capacity |
0.3-2.0m3/min |
|
Working ambient temperature |
-20°C~50°C |
|
Overall dimension (mm) |
6300(L)x2300(W) x3100(H) |
|
Configuration |
PCS-611A single pump cementing skid |
|
Engine |
Caterpillar C13 475hp@2100rpm |
|
Transmission |
Allision 4700OFS |
|
Triplex pump |
serva TPC600*4.5" |
|
Power unti |
Cummins hydraulic power unit 6BT5.9A 180HP@2500RPM |
|
Mixing system |
High energy recirculating Jetmixing system |
|
Density Control system |
ACM-III.1Auto control system |
|
Slurry recirculating pump |
Serva RA56 |
|
Booster centrifugal pump |
Serva RA45 |
|
Mxing water pump |
Serva RB23 |
|
Displacement pump |
2*10 BBL stainless steel tank |
|
Mixing tank volume |
1.6m3 |
The single pump cementing skid is equipped with an extended TPC600 piston pump, which makes packing maintenance easier.
Mixing power is provided by a separate power unit, which increases the actual operating power of the mainframe.
The power sources for the slurry recirculation pump and the triplex pump are independent, so slurry quality is not affected by fluctuations in triplex pump pressure or flow.
The special pressurized centrifugal pump makes the recirculation system and pressurized system independent of each other, avoiding the two systems affecting each other and improving the mixing quality.
High energy recirculation jet mixing system.
Off-center dry cement valve can effectively avoid bulk cement choking
Emergency shut-off system at the air inlet.
F300 non-radioactive densitometer is easy to clean, safe and reliable.
Simple operation, adapted to oilfield work habits.
10" operation screen for easy monitoring of work data
Portable wireless/wired data acquisition system.
